SVH80 | 800KG | Vibratory roller
Key Specifications
-Engine:Honda GX390 | Changchai Changfa 186F | Golden Flying Fish RD90N-1
-Power:9.7 | 6 | 5.88 KW
-Operating Weight:788 | 790 | 800 KG
-Exciting Force:30 KN
Our Service
-On-time Delivery
-Quality Assurance (one year)
-Customized Services (logo,packaging,graphic)
Product Description
Handheld double drum vibrating roller
FEATURES
- Equipped with famous brand power, quality assurancesuperior performance.
- Ergonomic streamlined body design, wide field of vision,beautiful appearance.
- Imported hydraulic variable pump and quantitative motor,stepless speed change, walking forward and backward.
- Adopt Japanese nsk bearing,Japanese mitsubosh V-belt.
- Electromagnetic clutch controls vibration for faster operation.
- Hydraulic steering, labor-saving, flexible and convenient operation.
- The product has passed CE certification.
| Model | SVH80 | SVH80C | SVH80S | |
| Weight | ||||
| Operating weight | kg | 788 | 790 | 800 |
| Static line load | n/cm | 58/63 | 59/64 | 61.5/65.5 |
| Size | ||||
| Full width | mm | 750 | ||
| Full length (with armrests flat) | mm | 2500/1800 | ||
| Full height (armrest upright) | mm | 1140/1710 | ||
| Package dimensions | mm | 1320*700*1730 | ||
| Drum width | mm | 680 | ||
| Drum diameter | mm | 355 | ||
| Wheel base | mm | 650 | ||
| Drive | ||||
| Engine brand | HONDA | CHANGFA CHANGCHAI | GOLDEN FLYING FISH | |
| Engine model | GX390 | 186F | RD90N-1 | |
| Engine type | gasoline four-stroke | diesel four-stroke | diesel horizontal water cooling | |
| Number of cylinders | 1 | |||
| Output power | kw | 9.7 | 6 | 5.88 |
| Rotating speed | rpm | 3600 | 3600 | 2400 |
| Electrical equipment | V | 12 | ||
| Drive mode | Variable displacement piston pump infinitely variable double wheel | |||
| Walking characteristics | ||||
| Speed | km/h | 0-6 | ||
| Theoretical climbing ability | % | 30 | ||
| Brake | ||||
| Working brake | Variable displacement piston pump | |||
| Turn | ||||
| Steering method | Hydraulic steerinรง | |||
| Steering system | Hydraulic support plate | |||
| Vibration system | ||||
| Vibrating drum | front +rear | |||
| Drive form | Hydraulic drive | |||
| vibration frequency | hz | 65 | 60 | |
| Vibration amplitude | mm | 0.5 | ||
| Exciting force | kn | 30 | ||
| Sprinkler system | ||||
| Form | Gravity shower | |||
| Capacity | ||||
| Hydraulic oil capacity | L | 28 | ||
| Fuel capacity | L | 6.5 | 5.5 | 10 |
| Water tank capacity | L | 30 | ||
